2024 Galaxy Sport Tiagra Mechanical

£999.99

£799.99

Meet the SUNPEED Galaxy Sport, built for speed, stability and serious fun. It pairs a lightweight aluminium frame with a carbon fork, Shimano Tiagra 20-speed shifting and powerful hydraulic disc brakes. It’s ready for fast training rides and long weekend miles.

Frame Size: XL

MLXL

Colour: White

Hurry, only 1 items left in stock!

Pickup available at VRIDE Shop

Usually ready in 24 hours

5 years frame warranty

Free delivery in the UK

14 days return

From 9.7kg

Shimano Tiagra Mechanical

35mm deep alloy rims

One piece integrated carbon cockpit

Up to 30mm max. recommended tyre clearance

Fully internal cable routing

Hydraulic disc brakes

Ultralight Aluminium Frame

Specifications

Frameset

Frame

SUNPEED Galaxy Sport Ultralight Aluminium Frame, Internal Cable Routing

Fork

SUNPEED Galaxy Sport Carbon Fork, Internal Cable Routing

Drivetrain

Shifters

Shimano Tiagra R4720, 20 Speed

Front Derailleur

Shimano Tiagra FD-R4700F, 2 Speed

Rear Derailleur

Shimano Tiagra RD-4700R, 10 Speed

Cassette

Sunshine CS-HG 11-32T, 10 Speed

Crankset

Senicx Integrated Alloy PR6-B1 50/34T, 10 Speed

Bottom Bracket

Senicx BB-BSA24R

Chain

KMC X10

Brakes

Shimano Tiagra R4770 Hydraulic Disc Brakes

Brake Levers

Shimano Tiagra R4720

Brake Rotors

Z8, 160mm, 6 Screws

Wheels & Tyres

Hubs

Front & Rear: ANV Q12, 24H Axle, 4 Sealed Bearings

Spokes

SLE Competition Straight Pull

Rims

ANV A35 Aluminium Disc Brake Rims

Tyres

CST CRD-02 700 x 28c, Black Wall

Cockpit & Finishing Kit

Seatpost

SUNPEED Galaxy Aluminium Seat Post, 350mm

Seat Clamp

SUNPEED Galaxy Aluminium Seat Post Clamp

Saddle

Selle Royal Saddle

Headset

Completely Hidden Sealed Cartridge Bearings

Handlebar

ANV Aluminium Integrated Cable Routing Handlebar

Handlebar Tape / Grips

High Elastic Race Level PU+EVA

Pedals

WELLGO DU Aluminium Pedals

Weight

Net Weight

9.7 kg

Specifications may vary by size and configuration and are subject to change without notice.

Find Your Size

Use your height as a starting point when choosing your frame size.

XXL

Recommended Height 187-195

XL

Recommended Height 180-187

L

Recommended Height 175-180

M

Recommended Height 168-175

S

Recommended Height 160-168

XS

Recommended Height 150-160

Size recommendations are a guide only. Rider proportions, flexibility and preferred riding position can affect the ideal frame size.

Geometry

	XXL	XL	L	M	S	XS
Recommended Rider Height (cm)	187-195	180-187	175-180	168-175	160-168	150-160
Stand Over Height (cm) (O)	828	804.8	777.7	749.2	723.1	696
Stack (mm)-(C)	590	571	552	530	516	505
Reach (mm)-(B)	399	393	387	385	377	368
Stack-to-Reach Ratio (STR)	1.48	1.45	1.43	1.38	1.37	1.37
Seat Tube (mm)-(D)	565	540	510	480	450	420
Top Tube (mm)-(A)	565.9	554.5	543.7	535.7	522.7	503.2
Head Tube (mm)-(F)	200	180	160	140	122	110
Seat Tube Angle-(G)	74.2°	74.2°	74.2°	74.2°	74.2°	74.2°
Head Tube Angle-(K)	72°	72°	72°	71.2°	72°	71°
Rear Centre (mm)-(I)	410	410	410	410	410	410
Front Centre (mm)-(N)	621.1	609	597	595.9	575.1	570.6
Wheelbase (mm)-(H)	1020.8	1008.7	996.6	995.5	974.5	970
BB Drop (mm)-(J)	71	71	71	71	71	71
Fork Length (mm)-(L)	364	364	364	364	364	364
Fork Rake (mm)-(M)	47	47	47	47	47	47
Handlebar Width (mm)	420	420	400	400	380	380
Riser Length (mm)-(E)	115	100	100	85	85	85
